The Ford Flathead V8: The Engine That Put Power in the People’s Hands

Ford Applications Using D4TZ-3600-A Steering Wheel & D3TZ-13A805-A Horn Pad Servicing the steering column on classic Ford vehicles often requires removing the steering wheel assembly. When working with steering wheel D4TZ-3600-A and horn pad D3TZ-13A805-A applications, the process is straightforward when approached in the correct sequence and with the proper tool. This guide outlines the removal procedure based on original shop notes and preserves the mechanical order of operations. Application Scope Applies to Ford vehicles equipped with: D4TZ-3600-A Steering Wheel D3TZ-13A805-A Horn Pad TOOL-3600 Steering Wheel Puller Application may vary by model year or steering column configuration. Always confirm fitment before ordering replacement components. Original Shop Notes Remove two screws holding horn pad Undo wiring clips for horn pad Loosen steering wheel nut Attach steering wheel tool Loosen wheel Remove tool and nut Remove wheel Step-By-Step Technical Interpretation 1. Remove Horn Pad Retaining Screws The horn pad is secured to the steering wheel by two screws. Removing these fasteners allows access to the internal wiring and steering wheel retaining nut. Use appropriate screwdriver to avoid damaging the screw head. 2. Disconnect Horn Pad Wiring Clips With the horn pad removed, carefully release the wiring clips connected to the horn contact assembly. These clips must be detached before steering wheel removal to prevent wire strain or terminal damage. 3. Loosen the Steering Wheel Retaining Nut Loosen the steering wheel nut but do not remove it completely at this stage. Leaving the nut partially threaded helps protect the steering shaft threads during puller use. 4. Install Steering Wheel Puller (TOOL-3600) Attach the steering wheel puller evenly to the threaded mounting holes in the wheel hub. The puller applies controlled pressure to separate the steering wheel from the tapered steering shaft. Using a puller prevents damage to the wheel hub and avoids stressing the column bearings or shaft splines. 5. Release the Steering Wheel from the Shaft Once the puller is properly secured, gradually tighten the tool until the steering wheel breaks free from the taper. After the wheel loosens, remove the puller and fully remove the steering wheel nut. The steering wheel can then be lifted off the column shaft. When Steering Wheel Removal Is Necessary Steering wheel removal is typically required during: Turn signal switch service Steering column restoration Column bearing inspection Steering wheel replacement Because the steering wheel is mounted on a tapered shaft, proper tool use is recommended to avoid damage. Restoration Considerations On older Ford steering columns, corrosion or age can increase resistance between the wheel hub and shaft taper. Controlled puller pressure is preferable to prying or hammering methods. Inspect wiring connectors and horn contacts while the assembly is disassembled. Access during wheel removal provides an opportunity to evaluate column components without additional tear down. Confirm steering column configuration and model year before ordering steering wheels, horn pads, or related steering components. Explore our full selection of classic Ford steering wheels, horn pads, and steering column components.

Tracing back the gears of time, the story of Ford's iconic "P-R-N-D-L" (affectionately pronounced "prindle") starts in the golden era of automotive innovation. This simple, yet memorable acronym represents the sequence of gears on an automatic transmission: Park, Reverse, Neutral, Drive, and Low. It's a nostalgic nod to the heyday of American car culture, beginning its journey in the 1950s. In 1951, Ford revolutionized their lineup by introducing the first "automatic" transmission in its cars. This was the birth of the P-R-N-D-L sequence, a groundbreaking innovation at the time. Imagine the delight of drivers who, for the first time, could shift gears with a smooth slide of the lever, just once – a far cry from the manual efforts of the past. It should also be noted that unlike todays automatics the early automatics would only start in neutral! The 1950s and 60s were a golden age for Ford. Cars were more than mere transport; they symbolized freedom, style, and the American dream. The P-R-N-D-L was an integral part of this. It wasn't just about the ease of shifting gears; it was about the experience. Each letter was a step in the ritual of driving, a connection between human and machine that modern digital interfaces can't replicate. Fast forward to today, and while cars have evolved with dizzying technology and efficiency, the charm of the classic Ford P-R-N-D-L endures. For enthusiasts and collectors, operating this gearshift isn't just a mechanical action; it's a trip down memory lane, a tactile piece of history that harkens back to the days of chrome, tailfins, and the open road. In essence, the P-R-N-D-L of classic Ford cars is more than just a gear sequence. It's a symbol of a bygone era, a testament to Ford's pioneering spirit, and an enduring part of America's automotive legacy.

FORD F100 HISTORY In 1953, Ford launched a fresh era of F Series pickups. The 1953 pickups were officially called F-100 and featured sleeker designs with an all-new cab and front end design. This generation of F Series pickups had larger measurements that included 55% larger windshield glass due to its curved design. With the wider cab you can seat 3 full size adults. 1953 Ford also improved chassis now available in 110” and 118” wheelbase (1948-52 is 114”). The gas tank was moved from behind the seat and now mounted on the outside of the frame below the driver’s side of the cab. The upgrades were designed to foster toughness and driving performance. The F Series pickups also took on new names. The F-2 became the F-250. The F-3 was renamed the F-350. Options included a dome light, cigarette lighter, ashtray, sun visors, radio, recirculating air heater and hot water heater. The new name was retained by the F-100 until Ford discontinued production of the F-100 after the 1983 model-year. In 1954 the all-new 239 CID "Y" block engine became available. The 1956 F-100 was celebrated for its perpendicular windshield pillars and its wraparound windshield. Available on the Custom Cab model is a wraparound rear window. The “Y” block 272 was now available as was the 223 6 Cylinder. The gas tank was moved back into the cab behind the seat. Assembly of the F-100 in this time took place mostly in Dearborn, MI. Ford also made approximately 101,000 to 184,000 models of the F100 in Sao Paulo, Brazil. SECOND GENERATION The second generation of the Ford F-100 ran from 1957 through 1960. The important styling change for this generation was a lower hood sitting flush on top of the front fenders. Ford launched its tradition of providing two different pick up box styles in this generation. Separate rear fenders were featured on the traditional Stepside design. The new released Styleside layout featured smooth sides as well as a far more streamlined look. New for 1958 was the use of four headlights, Ford continued this until 1960. In 1959, Ford began making the F-100 with a unique four wheel drive. Ahead of this new development, outside makers such as American and Marmon-Herrington and Coleman occasionally converted normal Ford trucks to four wheel drive. The next generation of the vehicles also marked an increase in sales of the optional eight-foot bed for the F-100, the typical length of the bed was six and a half feet. The eight-foot bed eventually eclipsed its smaller counterpart in popularity among F-100 motorists. Assembly continued to take place in the Ford plant in Dearborn, MI. THE 3RD GENERATION The new pickups were lower to the ground and wider than earlier versions. 1961 F-100 offered the optional uni-body, which combined the cab and box into one body. Ford discontinued the unibody design at the end of the 1963 production after it fared dismally in the marketplace. 1961 and 1962 Ford still used one piece hood side emblems. In 1963 new body side trim was now available on the styleside trucks with a red painted stripe in the center of the trim. The all new hood side emblem now included a plastic insert with the size of the truck “100”, “250”, “350”. In 1965 designers lowered the cab floor enhancing interior room. 1965 Ford also launched the first of its all new front suspension the "Twin I-Beam". 1965 Also offers a 352 "FE" motor instead of the “Y” block 292. The 6 Cylinder engine is also upgraded from the 223 to the new 240. Ford offered the Ranger option in 1965. The designation referred to your field of options that included an interior optional bucket seats with console and carpeting instead of a rubber floor mat. Ford changed some of its own assembly in this time to a plant in Cuautitlan, Mexico. FOURTH GENERATION Ford engineers continued their emphasis on pickups in 1967 that offered a degree of comfort which was similar to a car. 1967 Has new unique hood side emblems. 1967 offered new exterior trim, the body side trim is also new 1-1/4” wide with thin black line top and bottom as well as, available rocker trim. With the new designed cab now includes a new cargo light for the bed at the back of the cab above the rear window. 1968 Changed the hood side emblem to include a reflector. Lower bed side reflectors are standard. The exterior trim is now wider at 1-1/2” wide with the black thin line top and bottom. The Ranger option now includes a grille emblem. New for 1968 is interior door lock knobs. The exterior trim is changed again for 1970. The grille is all new with a plastic inert for either side of the grille. The front of the hood now has a trim going from side to side. The bed side reflector is moved from the lower bed side to the end of the body side trim and now has a light in it. The new Ranger and Ranger XLT trim is now 3-5/8” wide. The new wide trim is available with either black for the Ranger option or woodgrain for the Ranger XLT. 1971 The steering wheel is changed to a two spoke wheel with optional black or woodgrain horn pad. FIFTH GENERATION OF THE F100 AND INTRODUCTION OF THE F-150 The F-100 underwent major refinements for the fifth generation of the F Series, which ran from 1973 through 1979. Ford released the F-150, a fresh version, in 1973. The F-150 was essentially an F-100 with a spring package in the front and back that enabled the vehicle to carry a heavier load. Ford stopped production of the 4x4 F-100 in 1978. New grille with new plastic inserts for 1973 with the plastic insert now going around the headlight. The XLT option now included a grille emblem. The side trim was now available with a rubber insert down the center of the trim. The side reflectors now had light sockets with the front ones mounted in the front fenders and the rear still at the back of the bed trim. With the all new dash design trucks optioned with factory air conditioning now had vents in the dash for the air to go through and no longer was the air conditioning unit hanging from under the dash. 1974 Ford offered the new “Super Cab” with had a back bench seat and quarter windows behind the door. The new quarter windows were available fixed and with a pop out version. 1977 Offered a new exterior rim called “Race Trak” trim. The trim was a thin molding that started on the front fender at the grille and went down the side of the truck and curved up the bed side to meet the body side trim. Mid year 1978 Ford switch to square headlights which became standard for the F series trucks. Ford stopped producing the venerable F-100 entirely following the 1983 model year. Fans of Ford F-100 pickups and Ford automobiles in general are motivated to see cgfordparts.com. The site is an excellent resource for locating thousands of old Ford parts now in reproduction. The expert staff members are prepared to answer questions and share their knowledge of Ford restoration.
